6-5/8“ Cement retainer 17–32 lb/ft cementing packer (retainer type)
Products Information
-------------------------------
Products Name: 6-5/8“ Cement retainer 17–32 lb/ft cementing packer (retainer type)
Size: 6-5/8"
The cementing packer is a tool used for pressure cementing and repair/insulation operations.
The spool valve is controlled from the surface by moving the sealing assembly along the tubing string—simply lifting it (valve closes) or lowering it (valve opens).
The cementing packer is designed for quick and easy drilling-out and is ideally suited for long-term repair and isolation operations carried out at great depths, under high temperatures, or in high-risk conditions.
It can be set using a mechanical setting tool.
The components are locked against rotation to facilitate drilling-out.
Lock rings help prevent the sealing element from being pushed out.
Technical specifications:
Nominal diameter of production casing: 168.3 mm (6 5/8 in).
Casing weight: 17–32 lb/ft.
Minimum internal diameter of casing: 142.8 mm (5.625 in).
Maximum internal diameter of casing: 154.8 mm (6.094 in).
Outer diameter of bridge plug: 136.5 mm (5.375 in).
Maximum working pressure, not less than: 68.9 MPa (10,000 psi).
Maximum working temperature, not less than, °F [°C]: 250 [120].
The cementing packer (bridge plug) shall be manufactured in accordance with the requirements of GOST ISO 14310-2014.
The cementing packer (bridge plug) shall be manufactured according to the drawing in Appendix No. 1 to this technical specification.
