Onshore oil drilling rig

Onshore oil drilling rig

  1. Hoisting System

    • Mast/Derrick: 90–180 ft structural tower (API 4F compliant)

    • Drawworks: Heavy-duty winch with 1,000–3,000 HP capacity

    • Hook Load Capacity: 150–750 tons (depending on depth rating)

  2. Rotary System

    • Rotary Table: 27.5" or 37.5" (API 7K)

    • Top Drive (Optional): For faster pipe handling

  3. Mud Circulation System

    • Mud Pumps: Triplex/duplex (1,500–7,500 PSI)

    • Shale Shakers & Solids Control: For cuttings removal

  4. Power Generation

    • Diesel Engines/Gensets: 1,000–5,000 HP total output

    • Electric/Silent Rigs (Optional): For noise-sensitive areas

  5. Pipe Handling

    • Automatic Pipe Handler (Optional): Reduces manual labor

    • Catwalk & Monkeyboard: For drill pipe organization

  6. Mobility Options

    • Skid-Mounted: For short moves

    • Truck/Trailer-Mounted: Fast relocation

    • Modular Design: Easy transport in remote areas

Technical Specifications

  • Drilling Depth: 3,000–30,000+ ft

  • Wellbore Diameter: 6"–36" (surface hole to production casing)

  • Mud Tank Capacity: 500–2,000 bbl

  • Personnel Capacity: 20–50 crew members

Applications

  • Exploratory Drilling: Wildcat & appraisal wells

  • Production Drilling: Development wells

  • Workover Operations: Re-entry & recompletion

  • Unconventional Resources: Shale, tight oil & gas

Safety & Compliance

  • API 4F, 7K, 8C certified components

  • Blowout Preventer (BOP): API 16A compliant

  • OSHA & IADC safety standards

  • H2S & Gas Detection Systems
